Simple | round | with filament

Simple capillaries with filament

Our simple, round capillaries with filaments are available with solid or hollow filaments. We offer this product with solid filaments as standard in a number of wall thicknesses. We can also accommodate any specific size requirements, get in touch and we’ll be happy to discuss your options further.

View the capillaries with filaments we currently have in stock here:

Made from borosilicate glass 3.3
Minimum purchase: 100 units

Article number	Outer Ø (mm)	Inner Ø (mm)	Wall thickness (mm)	Filament (mm)	Length (mm)	Inquiries
1403575	1.00 ± 0.05	0.580 ± 0.05	0.21	0.1	75	Request information Article number added to the contact form (see below)
1403547	1.00 ± 0.05	0.580 ± 0.05	0.21	0.1	100	Request information Article number added to the contact form (see below)
1403550	1.00 ± 0.05	0.580 ± 0.05	0.21	0.1	150	Request information Article number added to the contact form (see below)
1403571	1.00 ± 0.05	0.580 ± 0.05	0.21	0.133	75	Request information Article number added to the contact form (see below)
1403501	1.00 ± 0.05	0.580 ± 0.05	0.21	0.133	100	Request information Article number added to the contact form (see below)
1403517	1.00 ± 0.05	0.580 ± 0.05	0.21	0.133	150	Request information Article number added to the contact form (see below)
1405218	1.00 ± 0.05	0.750 ± 0.05	0.125	0.1	75	Request information Article number added to the contact form (see below)
1405201	1.00 ± 0.05	0.750 ± 0.05	0.125	0.1	100	Request information Article number added to the contact form (see below)
1405208	1.00 ± 0.05	0.750 ± 0.05	0.125	0.1	150	Request information Article number added to the contact form (see below)
1404523	1.00 ± 0.05	0.800 ± 0.05	0.1	0.1	75	Request information Article number added to the contact form (see below)
1404502	1.00 ± 0.05	0.800 ± 0.05	0.1	0.1	100	Request information Article number added to the contact form (see below)
1404503	1.00 ± 0.05	0.800 ± 0.05	0.1	0.1	150	Request information Article number added to the contact form (see below)
1403570	1.20 ± 0.05	0.696 ± 0.05	0.252	0.16	75	Request information Article number added to the contact form (see below)
1403526	1.20 ± 0.05	0.696 ± 0.05	0.252	0.16	100	Request information Article number added to the contact form (see below)
1403529	1.20 ± 0.05	0.696 ± 0.05	0.252	0.16	150	Request information Article number added to the contact form (see below)
1406304	1.20 ± 0.05	0.764 ± 0.05	0.218	0.12	75	Request information Article number added to the contact form (see below)
1406301	1.20 ± 0.05	0.764 ± 0.05	0.218	0.12	100	Request information Article number added to the contact form (see below)
1406303	1.20 ± 0.05	0.764 ± 0.05	0.218	0.12	150	Request information Article number added to the contact form (see below)
1405219	1.20 ± 0.05	0.900 ± 0.05	0.15	0.12	75	Request information Article number added to the contact form (see below)
1405202	1.20 ± 0.05	0.900 ± 0.05	0.15	0.12	100	Request information Article number added to the contact form (see below)
1405210	1.20 ± 0.05	0.900 ± 0.05	0.15	0.12	150	Request information Article number added to the contact form (see below)
1403012	1.20 ± 0.05	0.960 ± 0.05	0.12	0.12	75	Request information Article number added to the contact form (see below)
1403003	1.20 ± 0.05	0.960 ± 0.05	0.12	0.12	100	Request information Article number added to the contact form (see below)
1403004	1.20 ± 0.05	0.960 ± 0.05	0.12	0.12	150	Request information Article number added to the contact form (see below)

Made from borosilicate glass 3.3
Minimum purchase: 100 units

Article number	Outer Ø (mm)	Inner Ø (mm)	Wall thickness (mm)	Filament (mm)	Length (mm)	Inquiries
1403574	1.50 ± 0.05	0.870 ± 0.05	0.315	0.15	75	Request information Article number added to the contact form (see below)
1403542	1.50 ± 0.05	0.870 ± 0.05	0.315	0.15	100	Request information Article number added to the contact form (see below)
1403549	1.50 ± 0.05	0.870 ± 0.05	0.315	0.15	150	Request information Article number added to the contact form (see below)
1403573	1.50 ± 0.05	0.870 ± 0.05	0.315	0.2	75	Request information Article number added to the contact form (see below)
1403512	1.50 ± 0.05	0.870 ± 0.05	0.315	0.2	100	Request information Article number added to the contact form (see below)
1403530	1.50 ± 0.05	0.870 ± 0.05	0.315	0.2	150	Request information Article number added to the contact form (see below)
1405215	1.50 ± 0.05	1.124 ± 0.05	0.188	0.15	75	Request information Article number added to the contact form (see below)
1405203	1.50 ± 0.05	1.124 ± 0.05	0.188	0.15	100	Request information Article number added to the contact form (see below)
1405207	1.50 ± 0.05	1.124 ± 0.05	0.188	0.15	150	Request information Article number added to the contact form (see below)
1403013	1.50 ± 0.05	1.177 ± 0.05	0.162	0.15	75	Request information Article number added to the contact form (see below)
1403005	1.50 ± 0.05	1.177 ± 0.05	0.162	0.15	100	Request information Article number added to the contact form (see below)
1403001	1.50 ± 0.05	1.177 ± 0.05	0.162	0.15	150	Request information Article number added to the contact form (see below)
1404524	1.50 ± 0.05	1.200 ± 0.05	0.15	0.15	75	Request information Article number added to the contact form (see below)
1404501	1.50 ± 0.05	1.200 ± 0.05	0.15	0.15	100	Request information Article number added to the contact form (see below)
1404519	1.50 ± 0.05	1.200 ± 0.05	0.15	0.15	150	Request information Article number added to the contact form (see below)
1403569	2.00 ± 0.10	1.160 ± 0.10	0.42	0.267	75	Request information Article number added to the contact form (see below)
1403513	2.00 ± 0.10	1.160 ± 0.10	0.42	0.267	100	Request information Article number added to the contact form (see below)
1403531	2.00 ± 0.10	1.160 ± 0.10	0.42	0.267	150	Request information Article number added to the contact form (see below)
1408018	2.00 ± 0.10	1.600 ± 0.10	0.2	0.2	75	Request information Article number added to the contact form (see below)
1404506	2.00 ± 0.10	1.600 ± 0.10	0.2	0.2	100	Request information Article number added to the contact form (see below)
1404518	2.00 ± 0.10	1.600 ± 0.10	0.2	0.2	150	Request information Article number added to the contact form (see below)
1403543	3.00 ± 0.15	1.740 ± 0.15	0.63	0.3	75	Request information Article number added to the contact form (see below)
1403551	3.00 ± 0.15	1.740 ± 0.15	0.63	0.3	100	Request information Article number added to the contact form (see below)
1403552	3.00 ± 0.15	1.740 ± 0.15	0.63	0.3	150	Request information Article number added to the contact form (see below)
