Standard NMR tubes
Our standard designs for your application
Our standard NMR tubes in the most commonly requested diameters of 3 and 5 mm and lengths of 178 mm (7 inch) and 203 mm (8 inch) are made from high-quality borosilicate glass 3.3 with a fine fire-polished rim and lens-shaped bottom. The standard tolerances correspond to the usual values.
A glassblower can be used when further processing these tubes as the glass used can be fused with standard laboratory glass. The tubes are shrink-wrapped in a packaging unit in quantities of 50. Larger packaging units are, of course, also possible.
- Minimum purchase: 100 units
- Closed at the end, fire-polished rim
| Article number | Outer Ø (mm) | Inner Ø (mm) | Wall thickness (mm) | Length (mm) | Inquiries |
|---|---|---|---|---|---|
| 2001749 | 2.95 ± 0.03 | 2.36 ± 0.03 | 0.295 | 178 (7″) |
|
| 2001770 | 2.95 ± 0.03 | 2.36 ± 0.03 | 0.295 | 203 (8″) |
|
- Minimum purchase: 100 units
- Closed at the end, fire-polished rim
| Article number | Outer Ø (mm) | Inner Ø (mm) | Wall thickness (mm) | Length (mm) | Inquiries |
|---|---|---|---|---|---|
| 2001745 | 4.95 ± 0.050 | 4.19 ± 0.050 | 0.38 | 178 (7″) |
|
| 2001748 | 4.95 ± 0.050 | 4.19 ± 0.050 | 0.38 | 203 (8″) |
|
- Lens shaped bottom, Rim fire-polished
- Packed as 50 tubes + 50 turquoise caps in sliding box
- Length: 178 mm (7")
- made of Borosilicate glass 3.3
- Minimum order: 1 Set
| Article number | Outer-Ø (mm) | Inner-Ø (mm) | Wall thickness (mm) | Special feature | Inquiries |
|---|---|---|---|---|---|
| 2001745-50 | 4.95 ± 0.05 | 4.19 ± 0.05 | 0.38 | - |
|
| 2001783-50 | 4.95 ± 0.05 | 4.19 ± 0.05 | 0.38 | with writing patch |
|
- Highest precision, exceptional surface quality, high volume
- Lens shaped bottom, Rim fire-polished
- Length: 178 mm (7")
- made of Borosilicate glass 3.3
- Minimum order: 10 pieces
| Article number | Outer-Ø (mm) | Inner-Ø (mm) | Wall thickness (mm) | Special feature | Inquiries |
|---|---|---|---|---|---|
| 2001797 | 4.97 ± 0.025 | 4.19 ± 0.025 | 0.38 | packed per 10 pieces |
|
| 2001798 | 4.97 ± 0.013 | 4.19 ± 0.013 | 0.38 | packed per 10 pieces |
|
| 2008231 | 4.9635 ± 0.0065 | 4.2065 ± 0.0065 | 0.3785 | Single packaged |
|
- Lens shaped bottom, Rim fire-polished
- Minimum order: 5 pieces
| Article number | Outer-Ø (mm) | Inner-Ø (mm) | Wall thickness (mm) | Length (mm) | Inquiries |
|---|---|---|---|---|---|
| 2009890 | 4.95 ± 0.05 | 4.19 ± 0.05 | 0.38 | 178 (7") |
|
We have launched a series of standard 100 mm high-precision NMR tubes, designed and developed in collaboration with the company Bruker.
They are specifically tailored to the devices and sample sizes for which the Bruker Match™ system was developed. Only top-quality borosilicate glass 3.3 is used in their manufacture, which is processed by us within tight tolerances. Dimensions range from 1 to 5 mm.
- Minimum order: 100 pieces
- Length: 100 mm
- Lens shaped bottom, Rim fire-polished
- made of Borosilicate glas 3.3
| Article number | Outer Ø (mm) | Inner Ø (mm) | Wall thickness (mm) | Inquiries |
|---|---|---|---|---|
| 2001727 | 1.0 ± 0.010 | 0.7 ± 0.010 | 0.15 |
|
| 2001710 | 1.7 ± 0.010 | 1.3 ± 0.010 | 0.2 |
|
| 2001711 | 2.0 ± 0.010 | 1.6 ± 0.010 | 0.2 |
|
| 2001712 | 2.5 ± 0.010 | 2.1 ± 0.010 | 0.2 |
|
| 2001724 | 3.0 ± 0.025 | 2.4 ± 0.025 | 0.3 |
|
| 2001725 | 4.0 ± 0.025 | 3.3 ± 0.025 | 0.35 |
|
| 2001734 | 4.25 ± 0.03 | 3.45 ± 0.03 | 0.4 |
|
| 2001726 | 5.0 ± 0.025 | 4.20 ± 0.025 | 0.4 |
|
